20mm Fan 2006 5V DC

Description

Raspberry Pi Fan 20mm 2006, Raspberry Pi Cooling Fan Brushless 5V DC Quiet Fan for Raspberry Pi 4 b, 3 b , 3, Pi 2, Pi B+, RetroFlag NESPI Case (20mmx20mmx06mm) (Black 2-Pack).



EDL2006C05 raspberry pi cooling fan is built for low-noise and durable cooling performance. This fan is suitable for Raspberry Pi B / Raspberry Pi B+ / Raspberry Pi A+ / Raspberry Pi 2 / Raspberry Pi 3 and Pi 4 model B. The One-to-Two wire connector pins of this fan, can get connected into Raspberry Pi 5V pin. This fan can be installed for most of the standard Raspberry Pi cases. Can be used for cooling Raspberry Pi 4, 3 B+, Thermoelectric Peltier Module  and other robotic projects.



Specifications:



– Fan Size: 20mm x 20mm x 6mm (LxWxH)

– Wire Length: 2.8 inches (70mm)

– Connector: One-to-Two pin

– Color: Black

– Bearing Type: CycleSeal Bearing

– Operating Voltage: DC 4.5V – 5.5V

– Start up Voltage: DC 3.5V

– Current: 90 mA

– Operating power: 0.3 W

– Speed: 8000RPM±20%

– Airflow: 0.42 CFM

– Air Pressure: 0.92 mmAq

– Noise Level: 14.1 dBA

– Motor protection: Polarity protection

– Life Time: 40,000 hours At 104 °F / 40℃ environment

– Unit weight: 2.7 gram

– Wire: UL1061/28AWG70mm

– Standard: RoHS compliance



Package Includes: 2 pieces EDM2006C05 Fan, together with screws and nuts mounting set.
